High-Speed SOI Wafers Low-Power Silicon-on-Insulator for ICs & MEMS High-Speed SOI Wafers Low-Power Silicon-on-Insulator for ICs & MEMS

High-Speed SOI Wafers Low-Power Silicon-on-Insulator for ICs & MEMS

SOI wafers, silicon-on-insulator where a thin layer of silicon sits on an insulating substrate, enable high-speed, low-power operation by reducing capacitance, leakage current, and enhancing switching speeds, widely adopted in microelectronics and emerging in photonics & MEMS.
  • item no. :

    CS-SOI-GP1001
  • Material : SiC

  • description

Properties of SiC Silicon Carbide SOI Wafers



  1. Enhanced Operational Speed:
    • Circuits built on SOI wafers offer a 30% increase in operational speed compared to those on traditional silicon substrates at specific voltages. This significant boost greatly enhances the performance of microprocessors and other devices, aligning with the demands for higher speeds in advanced electronics.
  2. Reduced Energy Consumption:
    • SOI wafers contribute to a substantial 30%-70% reduction in energy loss, making them ideal for applications where energy efficiency is paramount. This energy-saving capability is particularly valuable in power-intensive sectors, ensuring more sustainable operations.
  3. Improved Operational Durability:
    • SOI materials can withstand temperatures as high as 350°C to 500°C, demonstrating exceptional thermal stability. This robustness is crucial for devices that must perform reliably in harsh environments, ensuring uninterrupted performance in extreme conditions.
  4. Smaller Package Size:
    • SOI wafers cater to the growing demand for smaller IC packages, enabling IC manufacturers to meet the trend of miniaturization. This reduction in size not only supports the development of more compact devices but also aligns with the industry's push for increased integration and efficiency.



Applications of SiC Silicon Carbide SOI Wafers



  1. High-Speed Integrated Circuits:
    • SOI Wafers enable the creation of high-speed integrated circuits that are optimized for rapid data processing. They are ideal for applications requiring ultra-fast performance, such as data centershigh-frequency trading systems, and advanced computing platforms.
  2. High-Temperature Integrated Circuits:
    • With their ability to operate at elevated temperatures, SOI Wafers are perfect for high-temperature integrated circuits. This makes them crucial in industries like automotiveaerospace, and oil & gas, where devices must function reliably under extreme thermal conditions.
  3. Low-Power Integrated Circuits:
    • SOI Wafers support the development of low-power integrated circuits, critical for devices in the IoT (Internet of Things)wearable technology, and mobile computing sectors. Their energy-efficient design helps extend battery life and reduce overall power consumption.
  4. Low-Voltage Integrated Circuits:
    • These wafers are tailored for low-voltage integrated circuits, making them suitable for applications that require low power supply voltages. They are beneficial in embedded systemssensor networks, and portable electronics, ensuring efficient performance even with limited power sources.
  5. Microwave Devices and Power Devices:
    • SOI Wafers offer superior performance in microwave devices and power devices. They are essential for wireless communicationsradar systems, and power management solutions, delivering high efficiency and reliability in high-frequency and high-power applications.
  6. MEMS (Micro-Electromechanical Systems):
    • Leveraging SOI Wafers, MEMS can be designed with enhanced precision and reliability. They are pivotal in medical devicesautomotive sensors, and consumer electronics, enabling innovative functionalities and improved performance in miniaturized systems.





Size Chart of SiC Silicon Carbide SOI Wafers

Please provide drawing and parameter requirements for customization.


Item no. Wafer Diameter(μm) Device-layer Thickness(μm) Buried Thermal Oxide Thickness(μm) Handle Wafer Thickness(μm)
CS-SOI-GP1001 50±25μm 0.1-300μm 50nm(500Å)~15μm >100μm
CS-SOI-GP1002 75±25μm
CS-SOI-GP1003 100±25μm
CS-SOI-GP1004 125±25μm
CS-SOI-GP1005 150±25μm
CS-SOI-GP1006 200±25μm





REQUEST A FREE QUOTE
